How do you test a blower motor?

To test a blower motor, you can visually inspect it, check for power and voltage, test the motor’s resistance, and potentially test it with a direct power source. If the motor is not working, you may also need to check the capacitor and blower motor resistor.

Here’s a more detailed breakdown:

1. Visual Inspection:

Check for obstructions:

Ensure the fan blades are not blocked by debris or anything else that might prevent them from spinning freely.
Inspect for damage:

Look for any signs of damage to the motor itself, like burnt wires or melted plastic.

2. Check for Power:

Voltage test:

Use a multimeter to check for voltage at the blower motor terminals. If there is no voltage, the issue may be with the power supply or control circuit, not the motor itself.
Capacitor check:

If the motor has a capacitor, test it with a multimeter or by replacing it with a known good one, according to eMotors Direct.

3. Resistance Test:

Multimeter setting: Set your multimeter to measure resistance (ohms).
Terminal contact: Place the multimeter probes on the blower motor terminals.
Reading interpretation:
- A low resistance reading (close to zero) indicates good continuity (the circuit is complete).
- A high resistance or infinity reading indicates a break in the winding (open circuit).
- A reading within a certain range (e.g., 1-20 ohms) generally indicates a functional motor.

4. Bench Test (Optional):

Direct power:

If you have a known good power source, you can try connecting it directly to the blower motor to see if it spins. This helps determine if the motor itself is functional.
Safety first:

Be extremely careful when working with electricity. If you’re not comfortable with this test, it’s best to consult a professional.

5. Blower Motor Resistor:

Check for continuity: If the blower motor only works on some speeds, the blower motor resistor might be faulty. Use a multimeter to check its continuity and resistance.

Important Notes:

Always disconnect power before working on electrical components.
Refer to your vehicle’s or appliance’s manual for specific testing procedures and specifications.
If you’re unsure about any aspect of testing or repair, consult a qualified technician.
